Tropical Folding Minex - Antique and Vintage Cameras

Tropical Folding Minex

Model of c. 1922

Adams & Co.

London

England

Image of Tropical Folding Minex

Lens:
f4.5, 6 " Ross Xpres, iris diaphragm to f32. Serial no. 78039 (c. 1914).

Shutter:
Adams focal-plane, speeds 1/8 - 1/1000, B, T. Spring powered, adjustment by slit variation and choice of two tensioning springs. Self-capping.

Construction:
Polished teak with brass binding and fittings. Brown Russia leather bellows and hood.

Format:
3 " x 4 " plates held in double dark-slides.

Focusing:
Bellows to 25". Double extension.

Attributes:
Reflex viewing through taking lens. Full-size ground glass screen. Magnifier in hood.
Setting the shutter lowers the mirror where it locks, mirror raised by spring.
Revolving back. Removable lens panel. Spirit level.

Movements:
Rising front.

Notes:
Address on Camera: Adams & Co. 24 Charing Cross Rd. London. WC.

With:

  • f5.5, 13" Ross Teleros, iris diaphragm to f32. Focus to 64". On teak panel. With lens cap. Serial no. 128881 (c. 1934).
  • Film pack adapter. 3 tropical double dark-slides (1 - 6). Focusing back.
  • Instruction book c. 1925/26. Adams catalogue d. 1927.
  • Fitted case finished in crocodile for camera and accessories with removable canvas outer cover.

The Folding Minex was made in two distinct models, a third model is illustrated in the earliest advertisements but was probably a prototype or artist impression.

'Prototype'
(1914)
  • Lazy tongs connecting the front standard to the rear of the camera.
  • Front standard connects to inner focusing frame.
  • Small focusing wheel, fixed to folding bed, moves inner focusing frame. Focusing wheel on the right-hand side when using the camera.
  • Shutter release on the left-hand side.

1914 model
  • No lazy tongs.
  • Large focusing wheel on right-hand side.
  • Cut out for focusing wheel pinion.
  • Double extension by a folding rack.
  • Loose flap between camera top and the folded bed.
  • Release on left-hand side.

1922 model
  • Release on right-hand side.
  • No flap.
  • Focusing wheel on left-hand side.
  • Later models (c. 1925/26) have a separate IBT selector lever.

When originally produced the Folding Minex was available in 3 " x 4 ", 4" x 5" and 6 " x 4 " sizes. Later (c. 1919) a 2 " x 3 " model was made, postcard and 10 x 15 cm sizes were added in the 1920s.

The Tropical model was introduced around 1920. The camera was normally sold with a film pack adapter rather than slides. Standard lenses are in sunken mounts either wood or leather covered, telephoto lenses are surface mounted. Cases made of crocodile were advertised from 1926.

A cloth sleeve in the focusing hood is connected by a cord to the mirror mechanism. As the mirror is released so the sleeve moves within the hood to block out light from the hood.

References & Notes:
Minex shutter. BP 5523/1912. BP 25037/1913. BP 21588/1909. BJA 1914, p. 302. BJA 1915, p. 205. BJA 1916, p. 200. BJA 1920, p. 148. BJA 1922, p. 150. BJA 1923, p. 138. BJA 1927, p. 112.

Illustrations:
Holmes, Age of Cameras. Illustration of very late model with IBT selector. Christie's Cat. 28/10/1975 lot 65.
Christie's Cat. 11/12/2002. Illustration of very late model.
